GIGABYTE H810M GAMING WIFI6 Intel Core Ultra (Series 2) LGA 1851 Motherboard, mATX, DDR5, 1x M.2, PCIe 5.0, USB-C, WIFI6, 2.5GbE LAN, EZ-Latch
Supports Intel Core Ultra Processors (Series 2) DDR5 Compatible: 2*DIMMs
$98.71
$144.99
Save $46.28
H810M GAMING WIFI6
- Supports Intel Core Ultra Processors (Series 2)
- DDR5 Compatible: 2*DIMMs
- Thermals: VRM Thermal Armor, M.2 Thermal Guard
- Connectivity: PCIe 4.0, 1x M.2 Slots, USB-C, HDMI, DisplayPort
- DIY Friendly: M.2 EZ-Latch, PCIe EZ-Latch, WIFI EZ-Plug, EZ Debug Zone
- Networking: WIFI6, 2.5GbE LAN
Orders are handed to the carrier within 1 business day.
Free Shipping (3–5 business days) · Priority Shipping $9.90 (1–2 business days).
You have 30 days from the day your order is delivered to return unused items in their original condition and packaging. We pay for return shipping: you receive a prepaid label and nothing is deducted from your refund.
Once we receive and inspect the return, the refund goes back to your original payment method within 3 business days. Banks and card issuers may take another 3–10 business days to post it.
Each product is covered by its brand manufacturer's warranty. The term, what is covered, and how to make a claim are set by that manufacturer.
Email [email protected]. We reply within one business day.
Support covers shipping, returns, and order tracking.
Key features
Specifications
- Brand
- GIGABYTE
- CPU Socket Type
- LGA 1851
- CPU Type
- Intel Core Ultra Processors (Series 2)
- Chipset
- Intel H810
- Number of Memory Slots
- 2x288pin (DDR5)
- Memory Standard
- Support for DDR5 6400/5600
- Maximum Memory Supported
- 128GB
- Channel Supported
- Dual Channel
- Memory Performance Profile
- Intel XMP 3.0
- Memory Feature
- 2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- PCI Express 4.0 x16
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) * The PCIEX16 slot can only support a graphics card or an NVMe SSD.
- PCI Express x1
- 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)
- Serial ATA (SATA)
- 4 x SATA 6Gb/s
- M.2
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)
- SATA RAID
- 0/1/5/10
- Audio Channels
- 7.1 Channels
- Max LAN Speed
- 2.5Gbps
- Wireless LAN
- Wi-Fi 802.11 ax
- Bluetooth
- BLUETOOTH 5.3
- Back I/O Ports
- 1 x PS/2 keyboard/mouse port 1 x HDMI port (Note) 1 x DisplayPort (Note) 1 x USB 3.2 Gen 1 port 5 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks
- Onboard USB
- 1 x USB Type-C header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers
- Other Connectors
- 1 x CPU fan header 2 x system fan headers 2 x addressable RGB Gen2 LED strip headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x serial port
- BIOS Feature
- 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- Form Factor
- Micro ATX
- Dimensions (W x L)
- 9.6" x 8.5"
- Power Pin
- 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector
- Features
- Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Smart Backup
- MPN
- H810M GAMING WIFI6
- UPC
- 889523047941
